Holley Ultra HP Aluminium Fuel Bowl (HO134-78S)
Holley Ultra HP Aluminium Fuel Bowl (HO134-78S) is a special order in item. They take approximately 3 - 5 working days to arrive to us. Please get in touch with in prior to ordering if you are needing something more urgently.
Subscribe to our newsletter
Get the latest updates on all our new collections, sales, offers and product arrival dates.
Description
Description
HO134-78S - ULTRA HP ALUMINIUM FUEL BOWL
Tumble Polished Suit 4150, 4160 & 4500 Series Carburettors
Part Number: HO134-78S
Holley Billet Fuel Pressure Regulators are part of a complete line of fuel system products from Holley. They are precision machined from 6061-T6 billet aluminium for strength and durability. They feature a black bright dip anodized body and a clear bright dip anodized top for corrosion resistance and good looks. The Holley 12-847 fuel pressure regulator features (1) -10 AN O-ring inlet, (1) -10 AN O-ring outlet, (1) -8 AN O-ring return.
FEATURES :
Increased capacity
Will require a .250” longer fuel line
Material added to key areas (needle & seat, fuel inlets, sight window) for added strength in demanding race environments
Bowls can be plumbed from either side
Bowls offer contoured fuel entry for smooth fuel flow directly to needle & seat assembly
A threaded drain plug has been incorporated into the bowl
Fuel shelf to greatly minimize fuel aeration & promote more consistent metering
20% more fuel capacity vs. traditional V-Bowls, eliminates fuel starvation & provides consistent air/fuel ratios
Internal baffling cast into bowl
Fuel “trough” designed in floor of bowl to route fuel directly to jets & assists to keep jets covered
Features “Clear Pyrex” sight windows on both sides of bowl
Bowls use standard/traditional floats, float hangers, screws, accelerator diaphragms, etc.
use of o-ring fittings
drain plug
dual sight windows
baffling
Fuel bowl has 1/4 -16 fuel inlet threads (uses -8 Viton O-ring type fittings) Will not accept standard steel fittings
