PULSAR GTX3584 Gen 3 XR6 Turbo

$1,725.00
Tax included Shipping calculated at checkout.


Description



  • New Aerodynamic 10 blade billet compressor wheel flow more air over the stock cast or Gen1 11 blade billet wheel
  • Max Air Flow rate: ~90 lb/min, rated @ 1000 FWHP
  • Larger Turbine Wheel for higher flowability
  • Genuine structure and rebuildable dual ceramic ball bearing system
  • Larger 0.72A/R compressor cover with Anti-Surge 4″ inlet
  • Billet actuator with black anodized coating
  • 3 Layer Stainless Steel 5 Bolt Gasket

Description

  • Compressor Wheel: 67.3*84.4mm(extended tip diameter: 87.3mm)
  • Larger Turbine Wheel for Higher Horsepower: 74*66mm
  • Compressor Inlet: 4″ Hose
  • Compressor Outlet: 2.5″ Hose
  • Turbine Inlet: T3 Open
  • Turbine Outlet: 5 Bolt
  • Turbine housing internal wastegate hole: 33mm
  • Water Ports: -6AN
  • Oil Feed: -4AN to the Oil Restrictor
  • Oil Drain: Std T3 Oil Drain Flange
  • Actuator working pressure: 15psi/10psi/5psi

Application:

Replacement for factory XR6 PT3582 PT3576 Turbos.

  • 2002- BA FALCON XR6
  • 2004- BF FALCON XR6
  • 2008- FPV F6/TYPHOON/TORNADO
  • 2006- TERRITORY
  • 2008- FG FALCON XR6
  • 2008- FG FALCON G6E

    Payment & Security

    Payment methods

    • Apple Pay
    • Google Pay
    • Mastercard
    • Shop Pay
    • Visa

    Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

    LOOKING FOR A SPECIFIC PART?

    Share announcements and information with your customers and welcome them to your store.

    PULSAR GTX3584 Gen 3 XR6 Turbo - Prolink Performance
    Pulsar Turbochargers

    PULSAR GTX3584 Gen 3 XR6 Turbo

    From $1,725.00



    Description

    • Compressor Wheel: 67.3*84.4mm(extended tip diameter: 87.3mm)
    • Larger Turbine Wheel for Higher Horsepower: 74*66mm
    • Compressor Inlet: 4″ Hose
    • Compressor Outlet: 2.5″ Hose
    • Turbine Inlet: T3 Open
    • Turbine Outlet: 5 Bolt
    • Turbine housing internal wastegate hole: 33mm
    • Water Ports: -6AN
    • Oil Feed: -4AN to the Oil Restrictor
    • Oil Drain: Std T3 Oil Drain Flange
    • Actuator working pressure: 15psi/10psi/5psi

    Application:

    Replacement for factory XR6 PT3582 PT3576 Turbos.

    • 2002- BA FALCON XR6
    • 2004- BF FALCON XR6
    • 2008- FPV F6/TYPHOON/TORNADO
    • 2006- TERRITORY
    • 2008- FG FALCON XR6
    • 2008- FG FALCON G6E

    Compressor Housing Options

    • Standard
    • T51R Mod

    Turbine Housing Options

    • 1.06 A/R
    • 1.15 A/R

    Actuator Pressure

    • 5PSI
    • 10PSI
    • 15PSI
